Power Team® C152C SPXC152C
Power Team® C152C C Series General Purpose Spring-Return Single-Acting Hydraulic Cylinder, 15 ton Load, 5.88 in H Min, 8 in H Max, 2.13 in
- Manufacturer: SPX FLOW
- Brand Name: Power Team®
- Part Number: SPXC152C
- MPN: C152C
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at EVANSVILLE, IN
-
Check Availability at All Branches
-
Price:
Power Team® Hydraulic Cylinder, General Purpose Spring-Return Single-Acting, Series: C Series, 15 ton Load, 5.88 in Minimum Height, 8 in Maximum Height, 2.13 in Piston Stroke, 2-3/4 in Base Width
| Base Width | : | 2-3/4 in |
| Load Capacity | : | 15 ton |
| Maximum Height | : | 8 in |
| Minimum Height | : | 5.88 in |
| Piston Stroke | : | 2.13 in |
| Series | : | C Series |
| Type | : | General Purpose Spring-Return Single-Acting |
- Rugged, high quality cylinder used for lifting and pressing
- Aluminum bronze bearing reduces wear caused by off-center loads
- Maximum sized springs speed piston return and increase spring life
- Solid steel cylinder body for durability
- Chrome plated piston rod resists wear and corrosion
- Wide range of accessories available to thread onto piston rod, collar, or onto cylinder base
- Base mounting holes standard on 5 through 55 ton cylinder
