INA AXW15 INAAXW15
INA AXW15 Axial Needle Roller Bearing With Axial Bearing Washer, 15 mm Dia Bore, 31 mm OD, 3.2 mm W, 11300 N Dynamic/36000 N Static/3600 N Fatigue Load
- Manufacturer: Schaeffler Group
- Brand Name: INA
- Part Number: INAAXW15
- MPN: AXW15
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at EVANSVILLE, IN
-
Check Availability at All Branches
-
Price:
INA Axial Needle Roller Bearing, Series: AXW Series, 15 mm Bore Dia, 31 mm Outside Dia, 3.2 mm Width, Single Thrust Direction, 11300 N Dynamic/36000 N Static/3600 N Fatigue, 13200 rpm Maximum, -20 to 120 deg C
| Bore Diameter | : | 15 mm |
| Load Capacity | : | 11300 N Dynamic/36000 N Static/3600 N Fatigue |
| Maximum Speed | : | 13200 rpm |
| Outside Diameter | : | 31 mm |
| Series | : | AXW Series |
| Temperature Rating | : | -20 to 120 deg C |
| Thrust Direction | : | Single |
| Width | : | 3.2 mm |
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/INA_A_W15_Specification_Sheet.pdf
