INA 81102-TV INA81102TV
INA 81102-TV 811 Series Axial Cylindrical Roller Bearing, 15 mm Dia Bore, 28 mm OD, 9 mm W, 14400 N Dynamic/28500 N Static Axial/4000 N Fatigue Load
- Manufacturer: Schaeffler Group
- Brand Name: INA
- Part Number: INA81102TV
- MPN: 81102-TV
- Min. Order Qty: 1
- Qty. Interval: 1
-
Available at EVANSVILLE, IN
-
Check Availability at All Branches
-
Price:
INA Axial Cylindrical Roller Bearing, Series: 811 Series, 15 mm Bore Dia, 28 mm Outside Dia, 9 mm W, Open Closure, 14400 N Dynamic/28500 N Static Axial/4000 N Fatigue, Plastic Cage, 13600 rpm Maximum, -20 to 120 deg C
| Bore Diameter | : | 15 mm |
| Cage Material | : | Plastic |
| Closure Type | : | Open |
| Load Capacity | : | 14400 N Dynamic/28500 N Static Axial/4000 N Fatigue |
| Maximum Speed | : | 13600 rpm |
| Outside Diameter | : | 28 mm |
| Series | : | 811 Series |
| Temperature Rating | : | -20 to 120 deg C |
| Width | : | 9 mm |
- Plastic cage made from glass fiber reinforced polyamide 66
https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/INA_81102_TV_Specification_Sheet.pdf
